Linn LP12 Cartridges: Which Is Right for You?

Choosing between Linn LP12 cartridges is not simply a matter of moving from the least expensive option to the most expensive one. The cartridge has to work with the tonearm, the phono stage and the wider specification of the turntable, which means the right choice can be different for two LP12 owners with very different systems.

Linn’s current LP12 range illustrates that progression clearly. Majik can be specified with either the Adikt moving-magnet cartridge or Koil moving coil. Selekt LP12 uses Kendo moving coil, while Klimax LP12 is currently specified with Linn’s flagship Ekstatik moving-coil cartridge.

Those four names create a fairly neat hierarchy on paper.

In practice, the decision starts somewhere more useful: what do you already own, what can your phono stage accommodate and how far has the rest of the LP12 been developed?

If you are starting with the complete turntable rather than changing an existing cartridge, you can also explore Rococo’s complete Linn LP12 range.

Linn LP12 cartridges at a glance

The current Linn cartridge line-up associated with the LP12 spans one moving-magnet option and three moving-coil designs.

The key point is that each cartridge sits within a broader turntable configuration.

Majik with Adikt is not merely Majik with “the cheaper cartridge”. It is also the only current complete LP12 route in this group that remains moving magnet. Selekt and Klimax move further into Linn’s MC ecosystem and are partnered with increasingly ambitious arms and LP12 components.

Moving magnet vs moving coil: what actually changes?

Before comparing individual cartridges, it helps to understand the basic distinction between MM and MC.

Both types convert the mechanical movement of the stylus tracing a record groove into a small electrical signal.

The difference is in the generator arrangement inside the cartridge.

For the LP12 buyer, however, the most immediate practical distinction is usually the phono stage.

A moving-magnet cartridge requires an MM-compatible phono input. A low-output moving-coil cartridge requires a phono stage designed to provide the appropriate gain and electrical loading for MC operation.

That means moving from Adikt to Koil, Kendo or Ekstatik may have implications outside the turntable itself.

Your phono stage needs to be part of the decision.

Adikt: the current moving-magnet option

Adikt is the moving-magnet cartridge used in the current Majik LP12 MM specification.

This makes it the natural cartridge to consider if you want a current Majik LP12 and intend to use an MM phono stage.

The Majik LP12 MM therefore offers a particularly straightforward starting point for someone entering the LP12 ecosystem without simultaneously changing their phono amplification.

Who might Adikt suit?

Adikt is worth considering if:

• your existing amplifier or phono stage provides a suitable MM input
• you are buying your first current-specification LP12
• you prefer to develop the system gradually
• you do not currently plan to change your phono stage
• the rest of your LP12 remains around Majik level.

It is important not to dismiss moving magnet simply because Linn offers moving-coil cartridges above it.

System compatibility matters more than choosing a technology because it appears further up a hierarchy.

Koil: the first step into Linn moving coil

Koil is Linn’s current entry-level moving-coil cartridge and is available as the standard cartridge on Majik LP12 MC.

Linn explicitly positions Koil as the step above Adikt for customers who intend to use their Majik LP12 with moving-coil phono amplification.

The cartridge uses a nude Microlinear stylus and boron cantilever. Linn publishes a nominal tracking force of 2.0g and a load resistance of 100Ω for Koil.

Those figures matter during setup, but they are not buying arguments on their own.

The more useful consideration is whether moving coil makes sense within your existing system.

Who might Koil suit?

Koil becomes particularly relevant if:

• you want a Majik-level LP12 but prefer moving coil
• you already have suitable MC phono amplification
• you are replacing an Adikt and want to move into Linn’s MC range
• the rest of the turntable does not yet justify moving directly to a substantially higher cartridge.

If your phono stage is currently MM-only, remember that the cartridge is not necessarily the only part of the system that would need attention.

Kendo: the cartridge used with Selekt LP12

Kendo is the moving-coil cartridge fitted to the current Selekt LP12.

Linn designed Kendo specifically as a close partner for the Arko tonearm. Both use 7075-grade aluminium within their construction, and Linn describes Kendo as incorporating design principles developed through its work on Ekstatik.

Kendo uses a super-fine-line stylus and boron cantilever. Linn specifies an output of 0.45mV at 3.54cm/s, 100Ω load resistance and 2.0g tracking force.

Again, those technical specifications are important for correct matching and setup, but they should not be turned into simplistic claims that one cartridge will automatically produce a particular sonic result in every system.

Why Kendo and Arko belong in the same conversation

This is a useful example of why cartridge buying should not be separated from tonearm choice.

The current Selekt LP12 pairs Kendo with Arko as part of a complete Linn specification. It also combines them with Kore, Lingo and Trampolin.

If you already own an older LP12 and are considering Kendo, the question should therefore be broader than “Will it fit?”

You should consider the arm, phono stage and wider deck specification alongside it.

Ekstatik: the current flagship LP12 cartridge

Ekstatik sits at the top of Linn’s current cartridge hierarchy and is fitted as standard to Klimax LP12.

The current Klimax specification pairs Ekstatik with the Ekos SE tonearm, Keel sub-chassis, Radikal motor control and Urika II moving-coil phono stage.

That context is important.

Ekstatik is not simply the next cartridge to buy because you already own Koil or Kendo.

Within Linn’s own complete turntable range, it forms part of a flagship analogue system.

Who should consider Ekstatik?

It is most logically considered when:

• the rest of the LP12 is already at an appropriately high specification
• the tonearm is suitable
• you have appropriate MC phono amplification
• vinyl is a major part of your listening
• you are developing a high-level analogue source rather than upgrading one part in isolation.

If the surrounding LP12 is still comparatively modest, it may be worth considering whether investment elsewhere in the deck would produce a more coherent system before moving immediately to the flagship cartridge.

Linn LP12 cartridges: which should you choose?

The simplest answer starts with the LP12 you actually have.

Choose Adikt if…

You want a current Linn moving-magnet solution, your phono stage is MM-based and you are building or retaining a Majik-level LP12.

Consider Koil if…

You want to move from MM into moving coil at Majik level and already have, or plan to add, appropriate MC phono amplification.

Consider Kendo if…

Your LP12 is moving into Selekt territory, particularly around an Arko-based configuration, and the rest of the system supports that step.

Consider Ekstatik if…

You are building a substantially higher-level LP12 and want a cartridge aligned with Linn’s current flagship analogue configuration.

That framework is deliberately more cautious than saying “buy the best cartridge you can afford”.

A cartridge is only one part of the replay chain.

Do you need a new phono stage as well?

Possibly.

This is one of the most important questions to answer before changing cartridge type.

If you currently use Adikt with an MM input and decide to move to Koil, Kendo or Ekstatik, you need appropriate moving-coil phono amplification.

Some amplifiers or dedicated phono stages provide both MM and MC support. Others do not.

The settings available can also matter because moving-coil cartridges have requirements around gain and loading.

Do not order a cartridge first and work out how to amplify it afterwards.

Check the complete signal path before making the change.

Does the tonearm limit your cartridge choice?

The tonearm should always be considered when upgrading the cartridge.

The current Linn range gives a clear example of deliberate pairing:

• Krane sits within Majik LP12
• Arko is partnered with Kendo on Selekt LP12
• Ekos SE is partnered with Ekstatik on Klimax LP12.

That does not mean every LP12 has to mimic one of Linn’s complete factory configurations exactly.

Older Sondeks exist with many different arms and combinations.

It does mean that moving a cartridge far beyond the general level of the arm and deck deserves some thought.

If you are unsure what your existing LP12 can sensibly support, Rococo’s Linn upgrade service can help assess the complete specification before you choose a cartridge.

What if your current cartridge is simply worn?

Cartridge replacement is not always an upgrade decision.

The stylus is a wear item.

If your existing cartridge has significant use behind it, its history is unknown or it has been damaged, replacement may be a maintenance requirement first and an upgrade opportunity second.

This distinction matters with pre-owned LP12s.

A seller may describe an expensive cartridge as part of the deck’s value, but unless its age and usage are known, you should be cautious about assuming it has the same value as a new example.

If you are unsure of the condition of an existing cartridge, having the deck inspected through Linn servicing is more sensible than diagnosing stylus wear from sound alone.

Can you fit a higher cartridge to an older LP12?

Potentially, yes, but the fact that a cartridge can physically be installed does not mean it is automatically the most sensible upgrade.

With an older Sondek, establish:

• which tonearm is fitted
• the condition of the arm
• which sub-chassis is fitted
• the wider LP12 specification
• which phono stage is being used
• whether the deck is properly serviced and set up.

An older LP12 can contain a surprisingly modern collection of components after years of upgrades, so age alone is not the deciding factor.

The actual specification is.

Should you upgrade the cartridge or the LP12 first?

This is where the answer becomes genuinely individual.

If your cartridge is worn, replacing it may naturally come first.

If the cartridge is healthy but the LP12 retains a much older mechanical specification, it may be worth considering the bearing, sub-chassis or motor control before jumping several levels up the cartridge range.

If the turntable is already well developed but the cartridge is now the obvious remaining area, the opposite may be true.

There is no useful universal rule.

The right question is:

Which part of the current system is actually limiting the direction I want to take?

Why cartridge setup matters as much as cartridge choice

A good cartridge still needs to be installed correctly.

Alignment, tracking force, bias and tonearm setup all matter.

Linn publishes specific tracking and electrical requirements for its current cartridges, and those figures should be treated as setup specifications rather than optional suggestions.

This is particularly relevant when upgrading an existing LP12 because changing the cartridge can disturb a turntable that was previously correctly set up.

Professional installation also gives an opportunity to check that the arm and suspension remain correctly adjusted after the work.

Do not choose an LP12 cartridge from specifications alone

Technical specifications are necessary, especially for cartridge and phono-stage compatibility.

They are less useful as a prediction of which cartridge you will prefer listening to.

A stylus profile, cantilever material or output voltage tells you something factual about the design. It does not tell you how worthwhile the complete change will feel in your system.

This is where demonstrations and system context become more useful.

If you are buying a complete LP12, listening to Majik, Selekt or Klimax-level configurations gives you the cartridge as part of the deck Linn intended it to accompany.

If you are upgrading an existing turntable, the conversation needs to begin with its present specification.

Which Linn LP12 cartridge is right for your system?

If you want a simple starting point, think in terms of the complete analogue chain rather than the cartridge alone.

• Adikt: the current MM route for Majik LP12 and systems using suitable moving-magnet amplification.
• Koil: Linn’s current entry into moving coil, particularly relevant to Majik owners with appropriate MC amplification.
• Kendo: the moving-coil cartridge used with Selekt LP12 and designed as a partner for Arko.
• Ekstatik: the flagship moving-coil cartridge used within the current Klimax LP12 specification.

There is no benefit in choosing a cartridge that creates an imbalance elsewhere in the system simply because it occupies a higher position in the range.

The most sensible cartridge is the one that matches the tonearm, phono stage, LP12 specification and level at which you genuinely want the analogue system to operate.

Hear the cartridge as part of the complete LP12

The final decision is much easier when it moves away from specifications and back towards records.

If you are deciding between complete LP12 configurations, book a Linn demonstration and listen to familiar music rather than trying to predict the result from cartridge specifications alone.

Rococo Systems can demonstrate Linn equipment through our London Showroom and Epping Demonstration Facility, located between Ongar and Epping. For existing owners, we can also discuss whether a cartridge change makes sense alongside the tonearm, phono stage and the rest of the LP12.

Choosing between Linn LP12 cartridges is ultimately a system-matching decision. Adikt, Koil, Kendo and Ekstatik occupy clear positions within Linn’s current range, but the right one is the cartridge that makes sense for the turntable you own, the phono stage that follows it and where you want your LP12 to go next.
